Product Overview
- Panasonic WX-CS560 Attune Outdoor Speaker or Microphone. Two required per LANE
Panasonic Part WX-CS560 [ 2 required per Lane]
This product is the Speaker Microphone designed for the exclusive order posts to be used in combination with the Panasonic Wireless Communication System. The product can be used as a speaker or microphone. o While the slim and small-sized shape is compatible with the installation on most of the order posts, the product has accomplished the clear sound which can achieve the communication even under the engine noise.
o The provided brackets and urethane foams help the flexible mounting and speedy installation.
- Small enclosure of 4.5” x 4.5” x 2.75”
- Mounting brackets included
- Pre-packaged in speaker foam
- Wind screen and vibration canceling foam included
- Speaker is the same product as the Microphone
Information for Installation - Precautions for installation> (Not changed from WX-CS460.)
o This product is only installable inside the order post or similar structure, must not exposed outside or sunshine directly.
o Cushioning, wind screen, urethane foam box are consumable parts, periodic replacement is necessary. Supplied as service parts.
o Do not install upward from horizontal position to prevent standing water on the speaker unit.
o Do not install near the equipment or substance which are affected by magnetic field.
■ Specifications (Speaker Specification) (Not changed from WX-CS460.)
o Sound pressure level: 90 dB (1 W, 1 m , Typical) o Impedance: 8 ohms o Frequency response: 250 Hz - 15 000 Hz (-10dB , Typical) o Power capacity: 5 W (RMS*1) (Microphone Specification) (Not changed from WX-CS460.)
o Sensitivity: -52 dB (0dB=1V/Pa, 1kHz , Typical) o Frequency response: 100 Hz - 6 000 Hz (-10dB , Typical) (Miscellaneous) (Changed from WX-CS460. Connector on the end of the cable is removed.) o Input/Output: Stranded cables, connector is attached to the end.
o Cables Approximately 2700 mm two core shielded wire o Inner sheath color: Red: +, Black: ‒, Gray: GND
o Operating temperature: ‒20 °C to +50 °C {‒4 °F to 122 °F}
o Dimensions: 114 mm x 114 mm x 70 mm {4-1/2 inches (W) x 4-1/2 inches (H) x 2-3/4 inches (D)} (Excluding projections)
o Weight: Approximately 1.0 kg {2.2 lbs.} (without bracket) Approximately 1.2 kg {2.6 lbs.} (with brackets) o Finish: Plastic-molded, black *1 Rated noise power specified by IEC60268-5:2003+A1:2007(E)
Dimensions and weight indicated are approximate. 3
■ Accessories (Changed from WX-CS460. Connector is not included. )
o Bracket ...........................................................................2 pc.
o Mounting Screw ............................................................2 pc. o Gaskets for front panel and bracket...........................1 set
o Wind screen ...................................................................1 pc. o Operating Instructions .................................................1 pc.
o Urethane foam box .......................................................provided as part of packaging material
■ Information for Installation Precautions for installation> (Not changed from WX-CS460.) o This product is only installable inside the order post or similar structure, must not exposed outside or sunshine directly. o Cushioning’s, wind screen, urethane foam box are consumable parts, periodic replacement is necessary. Supplied as service parts. o Do not install upward from horizontal position to prevent standing water on the speaker unit. o Do not install near the equipment or substance which are affected by magnetic field.
MISCELLANEOUS:
Input/Output: Stranded cables, connector is attached to the end.
Cables: Approximately 2700 mm {106-5/16 inches} two core shielded wire
Inner sheath color: Red: + / Black: – / Gray: GND
Connector: Euro type 3P connector
Finish: Plastic-molded, black
SPEAKER:
Sound pressure level: 90 dB (1 W, 1 m {3.28 feet}, Typical)
Impedance: 8 Ω
Frequency response: 250 Hz to 15000 Hz (–10dB, Typical)
Power capacity: 5 W (RMS*1)
MICROPHONE:
Sensitivity: –52 dB (0 dB=1 V/Pa, 1 kHz, Typical)
Frequency response: 100 Hz - 6000 Hz (–10 dB, Typical)
*1 Rated noise power specified by IEC60268-5:2003+A1:2007(E), International Electrotechnical
